LIFCL-40-8MG121I LIFCL-40-9MG289I LIFCL-40-8BG256I LIFCL-40-7MG121A: FPGAs for Embedded Vision Processing

— Overview

The Lattice CrosslinkNx LIFCL-40-8MG121I, LIFCL-40-9MG289I, LIFCL-40-8BG256I and LIFCL-40-7MG121A (FPGA) are field-programmable gate arrays (FPGAs) designed for embedded vision processing and edge AI applications, They are based on 28 nm FD-SOI (Fully Depleted Silicon-on-Insulator) technology and are optimised for low-power, compact and high-reliability scenarios. These devices are well-suited for a wide range of applications, including embedded vision. Applications include sensor and display bridging, sensor aggregation, sensor replication and edge AI inference.

Features

1. Low power consumption and high reliability: Thanks to FD-SOI technology, the CrossLink-NX consumes up to 75% less power than comparable products. This technology also significantly enhances resistance to soft errors, reducing the soft error rate by up to 100 times and improving system reliability in harsh environments.

2. High-Performance Interfaces: Features built-in high-speed hardware interfaces, including a hard-core MIPI D-PHY with a data rate of up to 2.5 Gbps, 5 Gbps PCIe, and 1.5 Gbps programmable I/O. Supports multiple standards such as LVDS and subLVDS, facilitating direct connection to peripherals such as cameras and displays.

‌3. Rapid Configuration: Supports instantaneous I/O configuration (as fast as 3 milliseconds) and full device configuration (as fast as 8 milliseconds), facilitating rapid system boot-up and response times.‌

‌4. Compact Packaging: Offers a range of package sizes from 4 mm × 4 mm to 17 mm × 17 mm to meet the requirements of compact system designs.‌

Technical Specifications

1. LIFCL-40-8MG121I

Series: LIFCL-40

Number of logic elements: 39,000 LE

Number of inputs/outputs: 192 I/O

Supply voltage: 1 V

Operating Temperature: -40°C to +100°C

Mounting Style: SMD/SMT

Package: BGA-121

Distributed RAM: 240 kbit

Embedded Block RAM (EBR): 1512 kbit

2. LIFCL-40-9MG289I

Number of LAB/CLB: 9750

Number of logic elements/cells: 39,000

Total RAM bits: 1,548,288

Number of I/O pins: 180

Supply voltage: 0.95V – 1.05V

Mounting type: Surface-mount

Operating temperature: -40°C – 100°C (TJ)

Package/Housing: 289-CSBGA (9.5 x 9.5)

3. LIFCL-40-8BG256I

Number of LAB/CLB: 9750

Number of logic elements/cells: 39,000

Total RAM bits: 1,548,288

Number of I/O pins: 163

Supply voltage: 0.95V to 1.05V

Mounting type: Surface-mount

Operating temperature: -40°C to 100°C (TJ)

Package/Housing: 256-CABGA (14x14)

4. LIFCL-40-7MG121A

Number of LAB/CLB: 9750

Number of logic elements/cells: 39,000

Total RAM bits: 1,548,288

Number of I/Os: 72

Supply Voltage: 0.95V ~ 1.05V

Mounting Type: Surface Mount

Operating Temperature: -40°C ~ 125°C (TJ)

Package/Housing: 121-CSFBGA (6x6)

Application Scenarios

Mingjiada LIFCL-40-8MG121I, LIFCL-40-9MG289I, LIFCL-40-8BG256I, LIFCL-40-7MG121A (FPGA)

Embedded Vision Bridging: Converts MIPI CSI-2 sensor data into formats such as USB, LVDS and PCIe.

Multi-sensor Aggregation: Aggregates up to 11 MIPI CSI-2 sensors into a single output.

Edge AI Inference: Integrates an ISP (Image Signal Processor) pipeline (de-bayering, gamma correction, colour correction, etc.) and supports lightweight neural network inference.

Signal Duplication/Splitting: Duplicates a single video input to up to 14 outputs for safety redundancy or multi-screen display.

Industrial HMI: Supports intelligent interactive features such as real-time posture recognition and attention detection.
