104550-2

Part Number 104550-2

Manufacturer TE Connectivity AMP Connectors

Description CONN RCPT 20POS 0.05 GOLD SMD

Package -

Datasheet 104550-9.pdf 5-104550-6.pdf

Quantity

16288 In Stock

Fill out the form and we will contact you shortly.

Contact Information

Please send RFQ and we will contact you shortly.

Quantitiy

Contact Name* *

Email* *

Country

Company Name

Product Attributes

Type PARAMETERS

Categories

Features

Board Lock

Series

AMPMODU System 50

Contact Material

Phosphor Bronze

Fastening Type

Push-Pull

Number of Rows

Applications

Style

Board to Board

Pitch - Mating

0.050" (1.27mm)

Termination

Solder

Contact Finish Thickness - Mating

30.0µin (0.76µm)

Insulation Material

Polyphthalamide (PPA)

Number of Positions Loaded

All

Operating Temperature

-65°C ~ 105°C

Mated Stacking Heights

11.94mm, 13.08mm

Connector Type

Receptacle

Mounting Type

Surface Mount

Contact Finish - Post

Tin-Lead

Ingress Protection

Row Spacing - Mating

0.100" (2.54mm)

Contact Finish - Mating

Gold

Contact Shape

Square

Contact Finish Thickness - Post

150.0µin (3.81µm)

Base Product Number

104550

Contact Type

Female Socket

Contact Length - Post

Insulation Color

Black

Insulation Height

0.370" (9.40mm)

Material Flammability Rating

UL94 V-0

Product Status

Active

Number of Positions

Mfr

TE Connectivity AMP Connectors

Package

Tube

Current Rating (Amps)

Voltage Rating

30VAC

Documents & Media

RESOURCE TYPE LINK

PCN Design/Specification

E-16-016427(2).pdf
P-17-015214(2).pdf

3D Drawings

104550-2.pdf

Datasheets

104550-9.pdf
5-104550-6.pdf
