1571500000

Part Number 1571500000

Manufacturer Weidmüller

Description TERM BLOCK PLUG 18POS STR 5MM

Package -

Datasheet 1571500000.pdf

Quantity

81388 In Stock

Fill out the form and we will contact you shortly.

Contact Information

Please send RFQ and we will contact you shortly.

Quantitiy

Contact Name* *

Email* *

Country

Company Name

Product Attributes

Type PARAMETERS

Categories

Connectors, Interconnects , Terminal Blocks - Headers, Plugs and Sockets

Positions Per Level

Mfr

Weidmüller

Wire Gauge or Range - AWG

12-26 AWG

Screw Size

M2.5

Plug Wire Entry

180°

Current - UL

15 A

Torque - Screw

0.4-0.5 Nm (3.5-4.4 Lb-In)

Contact Material

Copper Alloy

Contact Tail Length

Series

Omnimate BL

Package

Bulk

Type

Plug, Female Sockets

Header Orientation

Material Flammability Rating

UL94 V-0

Wire Strip Length

7mm

Housing Material

Polybutylene Terephthalate (PBT)

Insulation Height

0.598" (15.19mm)

Number of Levels

Features

Retention Latches (Non-Wire Side)

Product Status

Obsolete

Voltage - IEC

400 V

Voltage - UL

300 V

Number of Positions

Current - IEC

19A

Pitch

0.197" (5.00mm)

Mounting Type

Free Hanging (In-Line)

Termination Style

Screw - Clamping Yoke (Tension Sleeve)

Wire Gauge or Range - mm²

0.5-2.5mm²

Color

Orange

Operating Temperature

-50°C ~ 100°C

Contact Mating Finish

Tin

Ingress Protection

IP20

Documents & Media

RESOURCE TYPE LINK

Datasheets

1571500000.pdf

PCN Obsolescence/ EOL

DK_OBS_NOTICE.pdf
