1612630000

Part Number 1612630000

Manufacturer Weidmüller

Description TERM BLOCK HDR 9POS 90DEG 7MM

Package -

Datasheet 1612630000.pdf

Quantity

98187 In Stock

Fill out the form and we will contact you shortly.

Contact Information

Please send RFQ and we will contact you shortly.

Quantitiy

Contact Name* *

Email* *

Country

Company Name

Product Attributes

Type PARAMETERS

Categories

Number of Levels

Contact Mating Finish

Silver

Current - IEC

Torque - Screw

Plug Wire Entry

Screw Size

Insulation Height

0.843" (21.41mm)

Package

Bulk

Mounting Type

Through Hole

Color

Gray

Housing Material

Thermoplastic, Wemid

Voltage - IEC

1 kV

Current - UL

14 A

Voltage - UL

600 V

Wire Strip Length

Header Orientation

90°, Right Angle

Wire Gauge or Range - mm²

Contact Tail Length

0.126" (3.20mm)

Mfr

Weidmüller

Series

Powermate STV

Wire Gauge or Range - AWG

Product Status

Obsolete

Operating Temperature

-50°C

Features

Mating and Mounting Flange

Ingress Protection

IP10

Contact Material

Copper Alloy

Type

Header, Blade Sockets

Number of Positions

Positions Per Level

Termination Style

Solder

Material Flammability Rating

UL94 V-0

Pitch

0.276" (7.00mm)

Documents & Media

RESOURCE TYPE LINK

Datasheets

1612630000.pdf

PCN Obsolescence/ EOL

PDN-PL335-2022_03_17_P046808_00-A.pdf

HTML Datasheet

1612630000-1.pdf
