640506-2

Part Number 640506-2

Manufacturer TE Connectivity AMP Connectors

Description CONN HEADER VERT 36POS 4.2MM

Package -

Datasheet 640506-3.pdf

Quantity

99468 In Stock

Fill out the form and we will contact you shortly.

Contact Information

Please send RFQ and we will contact you shortly.

Quantitiy

Contact Name* *

Email* *

Country

Company Name

Product Attributes

Type PARAMETERS

Categories

Overall Contact Length

Contact Finish - Mating

Gold

Contact Material

Phosphor Bronze

Operating Temperature

-55°C ~ 105°C

Mfr

TE Connectivity AMP Connectors

Fastening Type

Latch Lock

Pitch - Mating

0.165" (4.20mm)

Number of Rows

Contact Finish - Post

Tin-Lead

Shrouding

Shrouded - 4 Wall

Termination

Solder

Contact Length - Mating

0.220" (5.59mm)

Product Status

Active

Number of Positions Loaded

All

Contact Finish Thickness - Post

150.0µin (3.81µm)

Applications

General Purpose

Number of Positions

Row Spacing - Mating

0.165" (4.20mm)

Style

Board to Cable/Wire

Mounting Type

Through Hole

Series

MR (Miniature Rectangular)

Contact Shape

Circular

Insulation Color

Black, Red

Package

Bulk

Connector Type

Header

Contact Type

Male Pin

Material Flammability Rating

UL94 V-0

Voltage Rating

250VAC

Base Product Number

640506

Features

Ingress Protection

Mated Stacking Heights

Contact Length - Post

0.150" (3.81mm)

Insulation Height

0.531" (13.50mm)

Contact Finish Thickness - Mating

30.0µin (0.76µm)

Insulation Material

Polyamide (PA), Nylon

Current Rating (Amps)

Documents & Media

RESOURCE TYPE LINK

Datasheets

640506-3.pdf

3D Drawings

640506-2_2.pdf
