826658-9

Part Number 826658-9

Manufacturer TE Connectivity AMP Connectors

Description CONN HEADER VERT 18POS 2.54MM

Package -

Datasheet 826629-4.pdf

Quantity

16822 In Stock

Fill out the form and we will contact you shortly.

Contact Information

Please send RFQ and we will contact you shortly.

Quantitiy

Contact Name* *

Email* *

Country

Company Name

Product Attributes

Type PARAMETERS

Categories

Row Spacing - Mating

0.100" (2.54mm)

Product Status

Obsolete

Mfr

TE Connectivity AMP Connectors

Contact Material

Brass

Applications

Number of Rows

Contact Length - Post

0.126" (3.20mm)

Overall Contact Length

0.551" (14.00mm)

Contact Finish - Post

Tin

Style

Board to Board or Cable

Contact Finish Thickness - Mating

3.90µin (0.099µm)

Operating Temperature

-65°C ~ 105°C

Package

Bulk

Pitch - Mating

0.100" (2.54mm)

Number of Positions

Insulation Material

Polybutylene Terephthalate (PBT)

Mated Stacking Heights

Shrouding

Unshrouded

Mounting Type

Through Hole

Termination

Solder

Fastening Type

Push-Pull

Contact Shape

Square

Insulation Color

Green

Base Product Number

826658

Series

AMPMODU Mod II

Connector Type

Header, Breakaway

Contact Type

Male Pin

Contact Length - Mating

0.315" (8.00mm)

Material Flammability Rating

UL94 V-0

Voltage Rating

Number of Positions Loaded

All

Insulation Height

0.110" (2.79mm)

Contact Finish - Mating

Gold

Ingress Protection

Contact Finish Thickness - Post

118.1µin (3.00µm)

Features

Current Rating (Amps)

Documents & Media

RESOURCE TYPE LINK

Datasheets

826629-4.pdf

PCN Design/Specification

E-18-017808(2).pdf

3D Drawings

826658-9_2.pdf
